Brand

Hikvision

Product Type

Triple Signal Detector

Product Model

DS-PDTT15AM-LM-WB

Detection Performance

Detection Method

Passive infrared, microwave

Sensor Model

SFG323-711

Detection Range

15 m

Detection Angle

90° @ 180°adjustable

Detection Zones

92

Detectable Speed

0.3 to 2m/s

Sensitivity

Auto, low

White Light Filter

10000lux

Pet Immunity

40 kg

Microwave Frequency

24 GHz (24.15 to 24.25 GHz)

Digital Temperature Compensation

Support

Anti-Masking

Support

Adaptable Coverage

Support, Pattern mask included

Feature

Digital Processing

Tri-Signal logic

Sealed Optics

Support

Tamper Protection

Front, rear

Environment Temperature Indicator

Support

Signal Strength Indicator

Support

Anti-Sway Analytics

Support

Interface

Power Switch

Power up enrolling

LED Indicator

Green(top PIR), red(microwave), orange(bottom PIR), green orange(mask), blue(alarm)

Transmission

Transmission Technology

Tri-X wireless

Transmission Method

Two-Way RF wireless

Transmission Frequency

433 MHz

Transmission Security

AES-128 encryption

Transmission Range(Free Space)

1 km

Frequency Hopping

Support

Enrolling Method

Power up, remote ID, QR code

Electrical Characteristics

Standard Battery Life

Up to 5 years (standby time) (The battery working time can be significantly reduced at low temperatures)

Power Supply

Battery powered

Battery Type

CR123A × 5

Typical Voltage

3 V

General

Operation Temperature

-25°C to 60°C (-13°F to 140°F)

Storage Temperature

-25°C to 60°C (-13°F to 140°F)

Operation Humidity

10% to 90%

IP Rate

IP65

Mounting Method
